Bridge Human Identity with SPIFFE Workload Identity

Federate Vouch with SPIRE to bridge human and workload identity

Most organizations end up with two identity systems: one for humans (SSO, hardware keys) and one for workloads (service accounts, static secrets). SPIFFE (Secure Production Identity Framework for Everyone) solves the workload side — it gives every service a cryptographic identity (an SVID) that is short-lived, automatically rotated, and platform-agnostic. But SPIFFE does not address who deployed the workload or who authorized the action.

Vouch bridges that gap. Because Vouch is a standards-compliant OIDC provider, you can configure SPIRE (the SPIFFE reference implementation) to trust Vouch-issued tokens. This gives you a unified identity architecture where every credential — human or machine — is short-lived, cryptographically verified, and traceable.

How it works

Vouch and SPIRE operate at different layers of the identity stack:

Human layer (Vouch)                    Workload layer (SPIFFE/SPIRE)
─────────────────────                  ─────────────────────────────
YubiKey tap                            Workload attestation
  → Vouch OIDC ID token                 → X.509-SVID or JWT-SVID
    → kubectl, AWS, SSH, etc.              → mTLS, service-to-service auth

The integration points:

SPIRE trusts Vouch as an OIDC issuer — SPIRE validates Vouch tokens using the /.well-known/openid-configuration and JWKS endpoints to make authorization decisions based on hardware-verified human identity.
Workloads get SPIFFE SVIDs — SPIRE issues short-lived X.509 or JWT credentials to workloads via the Workload API, independent of any human session.
Both coexist in the same infrastructure — Humans authenticate with vouch login + YubiKey; services authenticate with SPIFFE SVIDs. Downstream systems (Kubernetes, AWS, databases) can accept both.

Prerequisites

Vouch CLI installed and enrolled — Complete the Getting Started guide.
SPIRE Server and Agent deployed — See the SPIRE Getting Started guide or the Kubernetes quickstart.
spire-server and spire-agent CLI tools available on your path.

Example 1: OIDC federation — Configure SPIRE to trust Vouch tokens

This is the foundational integration. You configure SPIRE to validate Vouch OIDC tokens so that human identity can inform workload registration and authorization decisions.

Register Vouch as a federated trust domain

Add a federation block to your SPIRE Server config so SPIRE automatically fetches and refreshes Vouch’s signing keys:

# spire-server.conf
server {
  trust_domain = "example.org"
  # ...
}

plugins {
  # Existing plugins...

  KeyManager "disk" {
    plugin_data {
      keys_path = "/opt/spire/data/keys.json"
    }
  }
}

# Federation with Vouch OIDC provider
federation {
  bundle_endpoint {
    address = "0.0.0.0"
    port = 8443
  }

  federates_with "vouch.sh" {
    bundle_endpoint_url = "https://us.vouch.sh"
    bundle_endpoint_profile "https_web" {}
  }
}

The https_web profile tells SPIRE to authenticate the endpoint using its public TLS certificate (standard web PKI). SPIRE fetches the JWKS from https://us.vouch.sh/.well-known/jwks.json and automatically refreshes it as keys rotate.

For air-gapped environments, fetch the keys manually and import them:

curl -s https://us.vouch.sh/.well-known/jwks.json -o vouch-jwks.json

spire-server bundle set \
  -id spiffe://vouch.sh \
  -format jwks \
  -path vouch-jwks.json

Note: The manual approach requires re-running these commands whenever Vouch rotates its signing keys. Prefer the automatic federation config above unless your SPIRE Server cannot reach https://us.vouch.sh.

Create workload registration entries with deployer identity

With federation in place, you can register workloads and tag them with the Vouch-authenticated deployer’s identity. This creates an audit trail from the human who deployed a workload to the SPIFFE identity the workload runs with:

# Register a backend API workload
# The "deployer" selector records who authorized this registration
spire-server entry create \
  -spiffeID spiffe://example.org/backend-api \
  -parentID spiffe://example.org/spire-agent \
  -selector k8s:ns:production \
  -selector k8s:sa:backend-api \
  -metadata "deployer:alice@example.com"

Validate Vouch tokens in a custom attestor

For advanced use cases, you can write a custom workload attestor plugin that validates a Vouch OIDC token presented by a workload during attestation. This lets workloads bootstrap their SPIFFE identity using a short-lived Vouch token:

# A workload requests a Vouch token with a SPIFFE-specific audience
vouch credential k8s --audience spiffe://example.org

# The custom attestor validates the token against Vouch's JWKS
# and maps the `sub` claim to a SPIFFE ID

Vouch token claim	SPIRE mapping
`iss`	Must match `https://us.vouch.sh`
`sub`	Maps to deployer identity metadata
`aud`	Must match the trust domain or a configured audience
`exp`	Token must not be expired
`amr`	Can require `["hwk", "pin"]` for hardware attestation

Example 2: Kubernetes with Vouch (human) + SPIFFE (service) identity

This is the most common deployment: a Kubernetes cluster where developers use Vouch for kubectl access and services use SPIFFE SVIDs for mutual authentication.

Architecture

Developer workstation              Kubernetes cluster
──────────────────────             ──────────────────
vouch login (YubiKey)              SPIRE Agent (DaemonSet)
  → vouch credential k8s             → Workload API (Unix socket)
    → kubectl (OIDC token)              → X.509-SVID per pod
                                          → mTLS between services

API Server validates both:
  - Vouch OIDC tokens (human access)
  - ServiceAccount tokens (SPIRE-managed workload access)

Configure kubectl with Vouch OIDC

Follow the Kubernetes guide to set up Vouch OIDC authentication for human access:

vouch setup k8s \
  --cluster production \
  --server https://k8s.example.com:6443 \
  --certificate-authority /path/to/ca.pem

Deploy SPIRE on Kubernetes

Deploy SPIRE Server and Agent using the official Helm chart:

helm repo add spiffe https://spiffe.github.io/helm-charts-hardened/
helm repo update

helm install spire spiffe/spire \
  --namespace spire-system \
  --create-namespace \
  --set global.spire.trustDomain=example.org \
  --set spire-server.controllerManager.enabled=true

Register workloads with SPIFFE IDs

Create registration entries that map Kubernetes workloads to SPIFFE identities:

# Backend API — gets an X.509-SVID for mTLS
spire-server entry create \
  -spiffeID spiffe://example.org/ns/production/sa/backend-api \
  -parentID spiffe://example.org/spire-agent \
  -selector k8s:ns:production \
  -selector k8s:sa:backend-api

# Frontend service — gets an X.509-SVID to call the backend
spire-server entry create \
  -spiffeID spiffe://example.org/ns/production/sa/frontend \
  -parentID spiffe://example.org/spire-agent \
  -selector k8s:ns:production \
  -selector k8s:sa:frontend

Application-level mTLS with SPIFFE

Services retrieve their SVIDs from the SPIRE Workload API and use them for mTLS. Here is a Go service that accepts connections only from peers with valid SPIFFE identities:

package main

import (
    "context"
    "log"
    "net/http"

    "github.com/spiffe/go-spiffe/v2/spiffeid"
    "github.com/spiffe/go-spiffe/v2/spiffetls"
    "github.com/spiffe/go-spiffe/v2/spiffetls/tlsconfig"
)

func main() {
    // Only accept connections from the frontend service
    allowedCaller := spiffeid.RequireFromString(
        "spiffe://example.org/ns/production/sa/frontend",
    )

    listener, err := spiffetls.Listen(
        context.Background(),
        "tcp", ":8443",
        tlsconfig.AuthorizeID(allowedCaller),
    )
    if err != nil {
        log.Fatal(err)
    }
    defer listener.Close()

    http.Serve(listener, http.HandlerFunc(func(w http.ResponseWriter, r *http.Request) {
        w.Write([]byte("authenticated via SPIFFE mTLS"))
    }))
}

And the frontend calling the backend over mTLS:

package main

import (
    "context"
    "io"
    "log"
    "net/http"

    "github.com/spiffe/go-spiffe/v2/spiffeid"
    "github.com/spiffe/go-spiffe/v2/spiffetls/tlsconfig"
    "github.com/spiffe/go-spiffe/v2/workloadapi"
)

func main() {
    ctx := context.Background()

    // Connect to the SPIRE Workload API
    source, err := workloadapi.NewX509Source(ctx)
    if err != nil {
        log.Fatal(err)
    }
    defer source.Close()

    // Create an HTTP client that presents our SVID
    // and verifies the backend's SPIFFE ID
    backendID := spiffeid.RequireFromString(
        "spiffe://example.org/ns/production/sa/backend-api",
    )

    tlsConfig := tlsconfig.MTLSClientConfig(source, source, tlsconfig.AuthorizeID(backendID))
    client := &http.Client{
        Transport: &http.Transport{TLSClientConfig: tlsConfig},
    }

    resp, err := client.Get("https://backend-api.production.svc:8443/data")
    if err != nil {
        log.Fatal(err)
    }
    defer resp.Body.Close()

    body, _ := io.ReadAll(resp.Body)
    log.Printf("Backend response: %s", body)
}

RBAC: both identity types on one cluster

Configure Kubernetes RBAC to handle both Vouch-authenticated humans and SPIFFE-authenticated services:

# Human access — developers authenticate via Vouch OIDC
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: vouch-developers
subjects:
  - kind: User
    name: alice@example.com   # From Vouch OIDC `sub` claim
    apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: ClusterRole
  name: edit
  apiGroup: rbac.authorization.k8s.io
---
# Service access — workloads authenticate via ServiceAccount tokens
# SPIRE manages the workload identity layer (mTLS between pods)
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: backend-api-access
  namespace: production
subjects:
  - kind: ServiceAccount
    name: backend-api
    namespace: production
roleRef:
  kind: Role
  name: backend-api-role
  apiGroup: rbac.authorization.k8s.io

Note: Vouch handles the human → API server authentication path via OIDC. SPIRE handles the pod → pod authentication path via X.509-SVIDs. The two systems are complementary — they do not replace each other.

Example 3: Multi-cloud service mesh with SPIFFE federation

For organizations running workloads across multiple clouds and on-premises, SPIFFE federation lets services authenticate across trust domain boundaries. Vouch provides the consistent human identity layer that operates across all environments.

Architecture

AWS (trust domain: aws.example.org)       GCP (trust domain: gcp.example.org)
──────────────────────────────────         ──────────────────────────────────
SPIRE Server (AWS)                         SPIRE Server (GCP)
  ↕ federation bundle exchange               ↕ federation bundle exchange
SPIRE Agents                               SPIRE Agents
  → X.509-SVIDs for AWS workloads            → X.509-SVIDs for GCP workloads

                    ↕ cross-cloud mTLS ↕

Human operators authenticate with Vouch across both environments:
  vouch login → vouch credential aws   (AWS access)
  vouch login → kubectl                (GCP GKE access)

Configure SPIFFE federation between clouds

Each SPIRE server exposes a bundle endpoint and federates with the other:

# AWS SPIRE server config
server {
  trust_domain = "aws.example.org"
}

federation {
  bundle_endpoint {
    address = "0.0.0.0"
    port = 8443
  }

  federates_with "gcp.example.org" {
    bundle_endpoint_url = "https://spire-server.gcp.example.org:8443"
    bundle_endpoint_profile "https_spiffe" {
      endpoint_spiffe_id = "spiffe://gcp.example.org/spire-server"
    }
  }
}

# GCP SPIRE server config
server {
  trust_domain = "gcp.example.org"
}

federation {
  bundle_endpoint {
    address = "0.0.0.0"
    port = 8443
  }

  federates_with "aws.example.org" {
    bundle_endpoint_url = "https://spire-server.aws.example.org:8443"
    bundle_endpoint_profile "https_spiffe" {
      endpoint_spiffe_id = "spiffe://aws.example.org/spire-server"
    }
  }
}

Register cross-cloud workloads

Allow a payment service in AWS to call a fraud detection service in GCP:

# On AWS SPIRE server — register the payment service
spire-server entry create \
  -spiffeID spiffe://aws.example.org/payment-service \
  -parentID spiffe://aws.example.org/spire-agent \
  -selector k8s:ns:payments \
  -selector k8s:sa:payment-service \
  -federatesWith spiffe://gcp.example.org

# On GCP SPIRE server — register the fraud detection service
# and allow calls from the AWS payment service
spire-server entry create \
  -spiffeID spiffe://gcp.example.org/fraud-detection \
  -parentID spiffe://gcp.example.org/spire-agent \
  -selector k8s:ns:ml-services \
  -selector k8s:sa:fraud-detection \
  -federatesWith spiffe://aws.example.org

Human access across clouds with Vouch

While services authenticate to each other via SPIFFE federation, human operators use Vouch for access to both environments:

# Authenticate once with YubiKey
vouch login

# Access AWS resources
vouch credential aws --role arn:aws:iam::111111111111:role/platform-engineer
aws eks update-kubeconfig --name production-aws

# Access GCP Kubernetes (via Vouch OIDC)
vouch setup k8s \
  --cluster production-gcp \
  --server https://gke.gcp.example.org:6443
kubectl --context production-gcp-vouch get pods

The result: every credential in the system is short-lived and traceable — human access via Vouch OIDC tokens, service-to-service via SPIFFE SVIDs, cross-cloud via SPIFFE federation.

Example 4: Zero-trust CI/CD with human approval gates

Combine SPIFFE workload identity with Vouch human approval to build a CI/CD pipeline where both the runner’s identity and a human authorization are cryptographically verified before a production deployment can proceed.

Architecture

Developer                    CI Runner                      Production
──────────                   ─────────                      ──────────
vouch login (YubiKey)        SPIFFE SVID (workload)         AWS / Kubernetes
  → OIDC token                 → attests runner identity      → requires both:
    → passed to CI job           → proves legitimate runner       1. valid SVID
                                                                  2. valid Vouch token

GitHub Actions workflow

name: Production Deploy

on:
  workflow_dispatch:
    inputs:
      vouch_token:
        description: 'Vouch OIDC token from deployer'
        required: true
        type: string

jobs:
  deploy:
    runs-on: self-hosted  # Runner with SPIRE Agent installed
    steps:
      - name: Verify deployer identity
        run: |
          # Validate the Vouch OIDC token
          # The token proves a human with a YubiKey authorized this deploy
          DEPLOYER=$(echo "${{ inputs.vouch_token }}" | \
            step crypto jwt inspect --insecure | \
            jq -r '.payload.sub')
          echo "Deployment authorized by: ${DEPLOYER}"
          echo "DEPLOYER=${DEPLOYER}" >> $GITHUB_ENV

      - name: Obtain SPIFFE identity
        run: |
          # The CI runner fetches its SVID from the local SPIRE Agent
          # This proves the runner is a legitimate CI workload
          /opt/spire/bin/spire-agent api fetch jwt \
            -audience sts.amazonaws.com \
            -socketPath /run/spire/sockets/agent.sock \
            -write /tmp/svid.jwt
          echo "Runner SPIFFE ID: $(cat /tmp/svid.jwt | \
            step crypto jwt inspect --insecure | \
            jq -r '.payload.sub')"

      - name: Deploy to production
        env:
          VOUCH_TOKEN: ${{ inputs.vouch_token }}
        run: |
          # Exchange the Vouch token for AWS credentials
          # The IAM role trust policy requires BOTH:
          #   1. A valid Vouch token (human authorization)
          #   2. The call to originate from an attested CI runner
          AWS_CREDS=$(aws sts assume-role-with-web-identity \
            --role-arn arn:aws:iam::ACCOUNT_ID:role/production-deployer \
            --role-session-name "deploy-${DEPLOYER}" \
            --web-identity-token "${VOUCH_TOKEN}")

          export AWS_ACCESS_KEY_ID=$(echo $AWS_CREDS | jq -r '.Credentials.AccessKeyId')
          export AWS_SECRET_ACCESS_KEY=$(echo $AWS_CREDS | jq -r '.Credentials.SecretAccessKey')
          export AWS_SESSION_TOKEN=$(echo $AWS_CREDS | jq -r '.Credentials.SessionToken')

          # Deploy with credentials tied to a specific human + runner
          kubectl apply -f k8s/production/

Trigger the deployment from a developer workstation

# Authenticate with YubiKey
vouch login

# Get a short-lived OIDC token for the CI/CD audience
DEPLOY_TOKEN=$(vouch credential aws \
  --role arn:aws:iam::ACCOUNT_ID:role/production-deployer \
  --format token)

# Trigger the deployment, passing the human authorization token
gh workflow run "Production Deploy" \
  --field vouch_token="${DEPLOY_TOKEN}"

IAM trust policy requiring both identities

The IAM role trust policy ensures that both the runner’s SPIFFE identity and the deployer’s Vouch identity are present:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "Federated": "arn:aws:iam::ACCOUNT_ID:oidc-provider/us.vouch.sh"
      },
      "Action": ["sts:AssumeRoleWithWebIdentity", "sts:TagSession"],
      "Condition": {
        "StringEquals": {
          "us.vouch.sh:aud": "us.vouch.sh",
          "us.vouch.sh:sub": [
            "alice@example.com",
            "bob@example.com"
          ]
        },
        "IpAddress": {
          "aws:SourceIp": "203.0.113.0/24"
        }
      }
    }
  ]
}

Note: The IpAddress condition restricts token exchange to your CI runner network. Combined with the SPIFFE SVID attesting the runner’s workload identity and the Vouch token attesting a human deployer, this creates a three-factor authorization chain: legitimate runner + authorized human + trusted network.

SPIFFE concepts reference

Concept	Description
SPIFFE ID	A URI that uniquely identifies a workload: `spiffe://trust-domain/path`
SVID	SPIFFE Verifiable Identity Document — an X.509 certificate or JWT that encodes a SPIFFE ID
Trust domain	The root of trust for a SPIFFE deployment (e.g., `example.org`)
Workload API	Local API (Unix socket) that workloads call to get their SVIDs and trust bundles
SPIRE Server	Central component that manages identities and issues SVIDs
SPIRE Agent	Per-node component that attests workloads and exposes the Workload API
Federation	Cross-trust-domain authentication via bundle exchange

For full details, see the SPIFFE specification and SPIRE documentation.

Troubleshooting

SPIRE cannot reach the Vouch OIDC discovery endpoint

Verify the SPIRE Server can make outbound HTTPS requests to https://us.vouch.sh/.well-known/openid-configuration.
Check network policies, firewall rules, and DNS resolution from the SPIRE Server pod or host.
Test connectivity: curl -s https://us.vouch.sh/.well-known/openid-configuration | jq .

SVID validation failures

Ensure the trust bundles are exchanged correctly between federated SPIRE servers. Check with spire-server bundle show.
Verify the workload registration entries match the actual pod selectors: spire-server entry show.
Check that the SPIRE Agent is running on the node where the workload is scheduled.

Token audience mismatch

The aud claim in Vouch tokens must match what SPIRE expects. When using vouch credential k8s, the default audience is kubernetes. For SPIFFE integration, specify a custom audience: vouch credential k8s --audience spiffe://example.org.
Verify with: vouch credential k8s --audience spiffe://example.org | jq -r '.status.token' | step crypto jwt inspect --insecure | jq '.payload.aud'

Clock skew causing JWT validation errors

SPIRE validates exp and nbf claims in Vouch tokens. Ensure clocks are synchronized across all nodes using NTP.
Vouch tokens are short-lived — even a few minutes of clock skew can cause validation failures.
Check the SPIRE Server logs: kubectl logs -n spire-system deployment/spire-server

“No identity issued” from Workload API

Confirm the SPIRE Agent is running: spire-agent healthcheck -socketPath /run/spire/sockets/agent.sock.
Verify that a registration entry exists for the workload: spire-server entry show -selector k8s:ns:YOUR_NAMESPACE -selector k8s:sa:YOUR_SERVICE_ACCOUNT.
Check that the workload’s service account and namespace match the registered selectors exactly.
